Announcing the launch of 622V withstand voltage High-side/Low-side driver IC
Contributes to downsizing of devices in a wide variety of applications including inverter circuits, AC/DC and DC/DC power supplies, and more

Dec. 7, 2021

Shindengen Electric Manufacturing Co., Ltd. has launched the MCZ5606SC/MCZ5607SC High-side/Low-side driver ICs.

In recent years there has been an increase in demand for stick-type vacuum cleaners, power tools, motorized bicycles, and other battery-equipped products and greater demand for downsizing, lighter weights, and energy saving for these products.
There is also demand for downsizing and lighter weight for the inverter circuits which are essential for reducing energy consumption in the three-phase brushless motors and other devices used in these products.
The number of air conditioners in operation worldwide continues to grow and in order to reduce energy consumption for these there has also been a rush of conversions of the fan motors in outdoor units to inverter types.

These products are High-side/Low-side driver ICs with 2 inputs and 2 outputs and built-in 622V withstand voltage elements.
They can directly drive MOSFETs and IGBTs used in inverter circuits and other applications, and can thereby reduce the number of components used in drive circuits to contribute to device downsizing and lighter weights.
In addition, the products also feature a simultaneous ON prevention function and under voltage lockout (UVLO) function which makes it possible to achieve extremely safe switching element control.

Features

  • High-side floating voltage
  • Output current(Source/Sink):220mA/450mA
  • Logic input voltage 3.3V, 5V compatible
  • VCC rated:22V
  • Simultaneous ON prevention function
  • Under voltage lockout (UVLO) function

Typical Applications

・Stick-type vacuum cleaners.
・Power tools.
・Motorized bicycles.
・Air conditioner / water heater outdoor unit fan motors.
・Drive parts for half-bridge circuits in various applications.

Reference circuit examples

  • examples for MCZ5606SC

Equivalent Circuit


Specifications

Item MCZ5601SC MCZ5606SC
New		 MCZ5607SC
New
High-side floating voltage 600V 622V 622V
VCC voltage 22V 22V 22V
Output current SOURCE 400mA 220mA 220mA
SINK 400mA 450mA 450mA
ton 210ns 240ns 240ns
toff 195ns 270ns 270ns
tr 33ns 75ns 75ns
tf 30ns 30ns 30ns
Package SOP8J SOP8J SOP8J
Simultaneous ON
prevention function		 Available Available Available
No. of inputs 2 2 2
No. of outputs 2 2 2
Terminal layout Terminal
layout 1		 Terminal
layout 1		 Terminal
layout 2

External Dimensions

  • Unit:mm


Terminal layout

Terminal layout 1

Terminal
No.		 Terminal
name		 Terminal
description
1 VCC VCC terminal
2 IN1 Input terminal 1
3 IN2 Input terminal 2
4 GND GND terminal
5 LO

Driver 2 output terminal
6 VS

Driver 1 reference terminal
7 HO

Driver 1 output terminal
8 VB

Driver 1 power supply terminal

Terminal layout 2

Terminal
No.		 Terminal
name		 Terminal
description
1 IN1 Input terminal 1
2 IN2 Input terminal 2
3 VCC VCC terminal
4 GND GND terminal
5 LO Driver 2 output terminal
6 VS Driver 1 reference terminal
7 HO Driver 1 output terminal
8 VB Driver 1 power supply terminal


Factory location

Higashine Shindengen Co., Ltd. (JPN) etc.


Contact information

Please note that the information contained in releases is current as of the date of press announcement, but may be subject to change without prior notice.
